PoE vs Traditional CCTV Wiring: What Every Installer Should Know

PoE has transformed how security camera systems get installed. One cable. Power and data. No separate power supply at every camera. For most installers working on IP systems today, PoE is the default — but understanding when and how to use it properly separates clean installs from callbacks.

This guide covers PoE vs traditional CCTV wiring, the practical differences that affect every install, and how to make the right call for any job.

Designing a larger system? Roylance Consulting provides expert CCTV system design and technical consulting for commercial and professional installations.

What Is PoE and How Does It Work?

Power over Ethernet (PoE) delivers electrical power alongside data through a standard Cat5e or Cat6 Ethernet cable. A PoE-capable switch or NVR detects whether a connected device supports PoE, then supplies power through the unused wire pairs in the cable.

For IP security cameras, this means:

• One Cat6 cable from NVR/switch to camera carries both video data and power
• No separate power supply or mains socket required at each camera location
• Cameras can be located anywhere a cable can be run — not just near power outlets

The power sourcing equipment (PSE) — your PoE NVR or switch — detects the powered device (PD), negotiates the required power level, and delivers it. Modern cameras typically draw 5–15W per camera depending on features (IR, PTZ, heater).

Traditional CCTV Wiring

Traditional CCTV systems — primarily analogue HD (HD-TVI, HD-CVI, AHD) and older analogue installations — use a different wiring approach:

• Coaxial cable (RG59 or RG6) for the video signal
• Separate power cable (18/2 or similar) run to each camera, or a centralised power supply with individual runs
• Some installers use Siamese cable (coax + power bundled) to reduce the number of separate runs

Each camera needs power from somewhere — either a local outlet, a DC power supply at the camera location, or a multichannel power supply at the DVR location with long runs back to each camera.

PoE vs Traditional: Side-by-Side

PoE Standards Every Installer Should Know

Not all PoE is equal. The standard determines how much power is available per port:

• 802.3af (PoE) — 15.4W available, 12.95W usable at the device. Sufficient for most standard IP cameras.
• 802.3at (PoE+) — 30W available, 25.5W usable. Required for cameras with high-power IR, PTZ motors, built-in heaters, or high-resolution sensors.
• 802.3bt (PoE++) — 60W or 100W available. Used for high-power PTZ cameras, access control panels, or VoIP systems.

Most 4MP turret and dome cameras (like the Titanium 4MP Turret) draw 7–12W and are comfortably powered by standard 802.3af. PTZ cameras or those with full-colour night vision illuminators may require 802.3at.

Always check the camera spec sheet for power consumption before selecting your NVR or switch. An undersized PSE will either refuse to power the device or power it in a reduced mode.

Cable Runs, Distance, and Signal Integrity

The 100m Rule

The IEEE standard for Ethernet over twisted pair is 100m (328ft) — this applies to both data and PoE power delivery. Beyond 100m, you risk:

• Signal degradation causing packet loss and dropped frames
• Voltage drop reducing available power to the camera (can cause instability or failure to boot)
• Intermittent issues that are difficult to diagnose

Practical Advice for Long Runs

• Use Cat6, not Cat5e, for runs approaching 80m+. The lower resistance of Cat6 helps with both signal and power delivery.
• Test every run over 80m with a cable tester before sealing walls. Resistance matters more at longer distances.
• PoE extenders can push distances to 200m+. Useful for outbuildings and perimeter cameras.
• Fibre + media converter for very long runs (200m+) where you need guaranteed performance.

Traditional Analogue: Distance Advantage

Analogue systems have a real advantage for long distances. RG59 coax can carry usable video signals for 300m+ without signal degradation. For rural properties, farms, or large perimeter systems where cable runs exceed 100m, analogue HD remains a practical choice — especially on existing coax infrastructure.

PoE NVR vs Separate PoE Switch: Which Do You Need?

Both get cameras connected, but the right choice depends on the job:

PoE NVR (Built-in PoE ports)

Units like the Titanium 4-Channel and 8-Channel PoE NVRs have PoE ports directly on the back of the unit. Cameras plug straight in.

Best for:

• 4–16 camera systems where cameras can be cabled back to a central location
• Simpler installs with less network infrastructure
• Clean installs in a single building

Separate NVR + PoE Switch

A standard NVR connects to a network, while cameras connect to PoE switches distributed around the building. The switch connects back to the NVR via uplink.

Best for:

• Large buildings with cameras spread across multiple floors or areas
• Installations where cameras are too far from the NVR to run individual cables
• Systems where cameras need to integrate with an existing network
• 16+ camera installs

The separate switch approach gives you more flexibility but adds complexity. For most residential and small commercial installs, a PoE NVR is simpler and cleaner.

When to Use Each: The Decision Guide

Use PoE IP when:

• New installation with no existing cabling
• Cable runs are under 100m to most cameras
• You need 4MP+ resolution
• Client wants remote access, smart features, or future expandability
• Single-cable installation efficiency matters (labour costs)

Consider analogue HD when:

• Replacing cameras on an existing coax infrastructure
• Cable runs exceed 100m regularly
• Client has a tight budget and 1080p is acceptable
• Simpler system with no network requirements

Use a hybrid DVR when:

• Upgrading an analogue system gradually — run new IP cameras while keeping existing analogue cameras on the same recorder
• Client wants to extend the life of existing coax runs

👉 See also: IP vs Analogue CCTV: Which System Is Right for You?

PoE Install Checklist

Frequently Asked Questions

Can I mix PoE and non-PoE cameras on the same NVR?

Depends on the NVR. Most PoE NVRs only support cameras on their built-in PoE ports — non-PoE IP cameras would need a separate power injector or PoE switch. Hybrid DVRs support both analogue and IP cameras simultaneously.

What happens if I exceed the 100m cable limit?

You may get intermittent camera dropouts, reduced image quality, or the camera may fail to receive enough power to boot. Test runs over 80m before committing. Use a PoE extender for runs you can’t shorten.

Is Cat5e acceptable for PoE camera runs?

Cat5e works for shorter runs under 60m. For longer runs or cameras with higher power draw, Cat6 is preferable — it has lower resistance and handles PoE power delivery more reliably over distance.

Do I need a UPS on a PoE NVR?

Strongly recommended. The NVR powers all cameras — a power cut takes the whole system offline. A UPS (uninterruptible power supply) provides 15–60 minutes of backup power, which is enough to ride out brief outages and ensures graceful shutdown to protect the HDD.

What’s the difference between PoE and PoE+?

Standard PoE (802.3af) delivers up to 15.4W per port. PoE+ (802.3at) delivers up to 30W. Most fixed-lens IP cameras are fine on standard PoE. PTZ cameras, cameras with built-in heaters or spotlight illuminators, and some high-res cameras require PoE+. Always check the spec sheet.
